UCFCF200

UCFCF200 ball bearing unit catalogue list

UCFCF200 - ball bearing unitUCFCF200 - ball bearing unit

Dimension
SPEC.1 Bore dia a p e i s J k g f z Bi n Bolt Used
UCFCF205 25(mm) 111 92 65.0 11 10.3 6.4 9.5 22 76.2 30.8 34.1 14.3 M8
UCFCF205-13 13/16(inch) 111 92 65.0 11 10.3 6.4 9.5 22 76.2 30.8 34.1 14.3 5/16
UCFCF205-14 7/8(inch) 111 92 65.0 11 10.3 6.4 9.5 22 76.2 30.8 34.1 14.3 5/16
UCFCF205-15 15/16(inch) 111 92 65.0 11 10.3 6.4 9.5 22 76.2 30.8 34.1 14.3 5/16
UCFCF205-16 1(inch) 111 92 65.0 11 10.3 6.4 9.5 22 76.2 30.8 34.1 14.3 5/16
UCFCF206 30(mm) 127 105 74.2 7.5 12 11 9.5 20 85.7 29.7 38.1 15.9 M10
UCFCF206-17 1-1/16(inch) 127 105 74.2 7.5 12 11 9.5 20 85.7 29.7 38.1 15.9 3/8
UCFCF206-18 1-1/8(inch) 127 105 74.2 7.5 12 11 9.5 20 85.7 29.7 38.1 15.9 3/8
UCFCF206-19 1-3/16(inch) 127 105 74.2 7.5 12 11 9.5 20 85.7 29.7 38.1 15.9 3/8
UCFCF206-20 1-1/4(inch) 127 105 74.2 7.5 12 11 9.5 20 85.7 29.7 38.1 15.9 3/8
UCFCF207 35(mm) 133 111 78.5 7.1 12 12 13 22 92 32.5 42.9 17.5 M10
UCFCF207-20 1-1/4(inch) 133 111 78.5 7.1 12 12 13 22 92 32.5 42.9 17.5 3/8
UCFCF207-21 1-5/16(inch) 133 111 78.5 7.1 12 12 13 22 92 32.5 42.9 17.5 3/8
UCFCF207-22 1-3/8(inch) 133 111 78.5 7.1 12 12 13 22 92 32.5 42.9 17.5 3/8
UCFCF207-23 1-7/16(inch) 133 111 78.5 7.1 12 12 13 22 92 32.5 42.9 17.5 3/8
UCFCF208 40(mm) 133 111 78.5 9.5 12 12 13 26 92 39.7 49.2 19 M10
UCFCF208-24 1-1/2(inch) 133 111 78.5 9.5 12 12 13 26 92 39.7 49.2 19 3/8
UCFCF208-25 1-9/16(inch) 133 111 78.5 9.5 12 12 13 26 92 39.7 49.2 19 3/8
UCFCF209 45(mm) 156 130 92 5.6 13.5 12 11.5 22 108 37.6 49.2 19 M12
UCFCF209-26 1-5/8(inch) 156 130 92 5.6 13.5 12 11.5 22 108 37.6 49.2 19 7/16
UCFCF209-27 1-11/16(inch) 156 130 92 5.6 13.5 12 11.5 22 108 37.6 49.2 19 7/16
UCFCF209-28 1-3/4(inch) 156 130 92 5.6 13.5 12 11.5 22 108 37.6 49.2 19 7/16
UCFCF210 50(mm) 162 137 96.5 8.69 13.5 16 13 27 114 41.3 51.6 19 M12
UCFCF210-29 1-13/16(inch) 162 137 96.5 8.69 13.5 16 13 27 114 41.3 51.6 19 7/16
UCFCF210-30 1-7/8(inch) 162 137 96.5 8.69 13.5 16 13 27 114 41.3 51.6 19 7/16
UCFCF210-31 1-15/16(inch) 162 137 96.5 8.69 13.5 16 13 27 114 41.3 51.6 19 7/16
UCFCF210-32 2(inch) 162 137 96.5 8.69 13.5 16 13 27 114 41.3 51.6 19 7/16
UCFCF211 55(mm) 181 152 108 5.6 15 22.2 13 22.2 127 39 55.6 22.2 M12
UCFCF211-32 2(inch) 181 152 108 5.6 15 22.2 13 22.2 127 39 55.6 22.2 7/16
UCFCF211-33 2-1/16(inch) 181 152 108 5.6 15 22.2 13 22.2 127 39 55.6 22.2 7/16
UCFCF211-34 2-1/8(inch) 181 152 108 5.6 15 22.2 13 22.2 127 39 55.6 22.2 7/16
UCFCF211-35 2-3/16(inch) 181 152 108 5.6 15 22.2 13 22.2 127 39 55.6 22.2 7/16

Findbearing.com supplies high quality UCFCF200 ball bearing unit.

Note:
– When the fit between bearing and housing is clearance fit, the outer ring of bearing has locking pin.
– As default structure, there is grease groove on the outer ring of the bearing. No grease groove structure can also be provided upon request.
