29438 thrust spherical roller bearing

29438 Bearing catalogue page.

Dimensions d 190 mm A 117 mm B 41 mm C 53.7 mm D 380 mm D1 345 mm d1 263 mm T 115 mm rmin 5 mm Basic load rating Co 2280 KN Cor 3900 KN Limiting speed grease 630 r/min oil 850 r/min Assembly dimensions damin 280 mm Da max 321 mm rg max 4 mm Weight 75.5 kg

– Default Brass cage material used electrolytic copper, different from recycled brass.
– Steel cage is also available on many items.
– Drawing according to ZWZ design, non-stealing material structure.
– Superior surface roughness, black chamfered.
– Well protected against knock wound.
