SS3300 stainless steel double-row angular contact ball bearing catalogue list
| Dimensions | Basic load ratings | Limiting Speed | ||||||||
| SPEC.1 | d | D | B | r | a | Cr | Cor | Grease | Oil | Mass |
| SS3300 | 10 | 35 | 19 | 0.1 | ||||||
| SS3301 | 12 | 37 | 19 | 0.12 | ||||||
| SS3302 | 15 | 42 | 19 | 1 | 26 | 14.2 | 11.8 | 9900 | 13000 | 0.127 |
| SS3303 | 17 | 47 | 22.2 | 1 | 28.5 | 17.5 | 15 | 9000 | 12000 | 0.185 |
| SS3304 | 20 | 52 | 22.2 | 1.1 | 32 | 21.1 | 18.6 | 8000 | 11000 | 0.221 |
| SS3305 | 25 | 62 | 25.4 | 1.1 | 38 | 29.4 | 26.8 | 6700 | 8900 | 0.354 |
| SS3306 | 30 | 72 | 30.2 | 1.1 | 44.5 | 39 | 36.5 | 5700 | 7600 | 0.55 |
| SS3307 | 35 | 80 | 34.9 | 1.5 | 50 | 49.5 | 47.5 | 5000 | 6600 | 0.756 |
| SS3308 | 40 | 90 | 36.5 | 1.5 | 55 | 54.5 | 57.5 | 4400 | 5900 | 1.03 |
| SS3309 | 45 | 100 | 39.7 | 1.5 | 61 | 67.5 | 72.5 | 4000 | 5300 | 1.37 |
| SS3310 | 50 | 110 | 44.4 | 2 | 67 | 81.5 | 89.5 | 3600 | 4800 | 1.98 |
| SS3311 | 55 | 120 | 49.2 | 2 | 75 | 96.5 | 108 | 3300 | 4400 | 2.42 |
| SS3312 | 60 | 130 | 54 | 2.1 | 82 | 113 | 128 | 3000 | 4000 | 3.07 |
| SS3313 | 65 | 140 | 58.7 | 2.1 | 88.5 | 131 | 150 | 2800 | 3700 | 3.9 |
| SS3314 | 70 | 150 | 63.5 | 2.1 | 97 | 153 | 168 | 2600 | 3500 | 5.2 |
| SS3315 | 75 | 160 | 68.3 | 2.1 | 104 | 172 | 191 | 2400 | 3200 | 6.3 |
| SS3316 | 80 | 170 | 68.3 | 2.1 | 113.1 | 175 | 192 | 2400 | 3200 | 7.21 |
| SS3317 | 85 | 180 | 73 | 2.1 | 188 | 190 | 210 | 2200 | 3300 | 8.30 |
| SS3318 | 90 | 190 | 73 | 3 | 125.5 | 205 | 242 | 2100 | 2800 | 9.23 |
Findbearing.com supplies high quality SS3300 stainless steel double-row angular contact ball bearing.
